YEV104/YEV105

YEV-104 YEV-105 YEV104PRO YEV105PRO
Dimensions Length 592mm (23-5/16") 607mm (23-7/8") 592mm (23-5/16") 607mm (23-7/8")
Width 204mm (8-1/16") 204mm (8-1/16") 204mm (8-1/16") 204mm (8-1/16")
Height 111mm (4-3/8") 120mm (4-3/4") 111mm (4-3/8") 120mm (4-3/4")
Weight Weight approx. 560 g approx. 590 g approx. 510 g approx. 550 g
Size 4/4 4/4 4/4 4/4
Body Spruce/Mahogany/Maple Spruce/Mahogany/Maple Spruce top and Maple back 2 layered Spruce top and Maple back 2 layered
Side/Frame Walnut Walnut Walnut Walnut
Neck Maple Maple Maple Maple
Finger Board Composite Composite Maple Maple
Bridge Maple with built-in Piezo-electric Pickup Maple with built-in Piezo-electric Pickup ARE treatment applied Maple with built-in Piezo-electric Pickup ARE treatment applied Maple with built-in Piezo-electric Pickup
Tuning Pegs Ebony Ebony Wittner Fine Tune Peg Wittner Fine Tune Peg
Tailpiece Synthetic Resin (equipped with fine tuners) Synthetic Resin (equipped with fine tuners) Synthetic Resin (equipped with fine tuners) Synthetic Resin (equipped with fine tuners)
Chin Rest Composite Composite Ebony Ebony
Strings D’Addario Zyex D’Addario Zyex (D’Addario Helicore on C-string) D’Addario Zyex D’Addario Zyex (D’Addario Helicore on C-string)
Pick Up System Bridge w/ Built-in Piezo-electric Pickup Bridge w/ Built-in Piezo-electric Pickup Bridge w/ Built-in Piezo-electric Pickup Bridge w/ Built-in Piezo-electric Pickup
Controls Volume Control, Selector Switch (Volume Control activation switch) Volume Control, Selector Switch (Volume Control activation switch) Volume Control, Selector Switch (Volume Control activation switch) Volume Control, Selector Switch (Volume Control activation switch)
Output Passive Output (Φ6.3 Standard Monaural) Passive Output (Φ6.3 Standard Monaural) Passive Output (Φ6.3 Standard Monaural) Passive Output (Φ6.3 Standard Monaural)
Logo Pad Printing Tuning Fork Mark Pad Printing Tuning Fork Mark Electroforming Tuning Fork Mark Electroforming Tuning Fork Mark
Color Natural / Black Natural / Black Deep Red / Natural and Brown / Natural and Black Deep Red / Natural and Brown / Natural and Black
