| General specifications |
| Speaker type |
Full-range bass-reflex powered speaker |
| Frequency range (-10dB) |
80Hz-20kHz |
| Nominal coverage |
160°conical |
| Component configuration |
6.4 cm (2.5-inch) full-range driver |
| Maximum output level |
97 dB SPL |
| Power rating |
Dynamic |
15W (PoE+(IEEE802.3at)), 6W (PoE(IEEE802.3af)) |
| Continuous |
15W (PoE+(IEEE802.3at)), 6W (PoE(IEEE802.3af)) |
| Dimensions (Φ x D) |
∅225 × D133 mm (including grille) |
| Weight |
1.8 kg (including grille) |
| In Operation |
Temperature |
0 °C - 40 °C |
| Humidity |
30% - 90% (non-condensing) |
| Storage |
Temperature |
−20 °C - 60 °C |
| Humidity |
20% - 90% (non-condensing) |
| Acabado |
White |
| I/O connectors |
RJ-45 (PoE/Dante) x1 |
| Controls |
8-switch DIP switch × 1 |
| Indicators |
Power (front), SYNC (RJ-45), LINK/ACT (RJ-45) |
| Protection circuit |
Speaker processing |
Overheating protection, overpower output protection, overvoltage input protection |
| Amplifier protection |
Overheating protection, short circuit protection, DC detection protection, overvoltage protection, undervoltage protection |
| Power supply protection |
Overcurrent protection, overheating protection |
| Cooling |
Natural air cooling |
| Power requirements |
PoE+ (IEEE 802.3at), PoE (IEEE 802.3af) |
| Power consumption |
Idle : 4.0W, 1/8 : 6.2 W (PoE+ (IEEE 802.3at)), 4.9 W (PoE (IEEE 802.3af)) |
| Maximum power consumption |
25.5 W (PoE+ (IEEE 802.3 at)), 12.95 W (PoE (IEEE 802.3 af)) |
| Magnetic shielding |
Non-magnetic shielding type |
| Dust and water resistant |
Non-compliant |
| Certificate |
VCCI |
| Signal Processing |
EQ/Enhancer, Volume, PEQ, Ducker (noise gate), Mixer, Delay, Speaker EQ (6 band) |
| Options |
Reinforcing bracket kit AB-C2 |
| Accessorios |
Grille, cutout template, safety wire, Owner’s Manual, Safety Guide, Installation/Dimensional diagrams |
