The PHX Series, from the YAMAHA Drum Laboratory

Prototype drums, which are the core of the evolution in YAMAHA drums, are created in the Drum Laboratory where YAMAHA pursues the essence of drums. Under a completely new concept, the PHX (a.k.a. phoenix) Series is the pinnacle of excellence in this prototyping process. Handcrafted by our expert technicians, it’s based on 40 years of history and experience.

The newly developed PHX Series proclaims YAMAHA’s all-out pursuit of the ultimate in drum potential for the next 40 years.

Hybrid Shell

The unique Hybrid shell was designed to perfectly achieve the three targets of the PHX concept - more volume, more tone and more dynamic range.

The shell uses the heaviest and hardest wood in the centre core, and the wood plies get gradually softer toward the inner and outer surfaces. This construction allows the shell to vibrate perfectly, free of constraint.

The shell uses the hardest and heaviest wood, Jatoba for the centre core. The Jatoba is surrounded on either side by layers of Kapur, another hard and heavy wood. Then, surrounding the Kapur is North American Maple, the softest wood in the whole shell, which is used for the outer and inner shell plies.

Countless trials, prototyping and sound checking with artists went into finding the perfect shell make-up for PHX.

Bearing Edge

The bearing edge is the single most important element to dictate the tone and articulation of each PHX shell.

All PHX bearing edge are cut at 30-degrees. However, what makes each type of shell different - whether it be a tom, floor tom, or bass drum - is the radius of the top of each bearing edge. These radiuses are where the drum head touches the wood of the shell, and the size of the radius allows more or less vibration to pass from the head through to the shell.

Therefore, the bass drum edge creates a clearer and sharper sound, while the tom edge makes a fatter and more rounded sound.

The bearing edges are shaped by craftsmen who have specialized knowledge of the characteristics of each wood. During rounds of sanding and special surface finishing, each edge gradually becomes perfectly shaped for its intended use.

Hardware

The lugs, tom mounting system and hoops have a crucial role in achieving the perfect drum sound.

The PHX uses the Y.E.S.S.Ⅱ system for mounting the toms, which is perfectly matched to the hybrid shell. It is super stable and comfortably supports the thick PHX shell while bringing out its natural resonance without compromise. The mounting plate itself is made of the same maple as is used on the outer plies of the Hybrid shell, further contributing to the rich resonance and enhanced low end.

The Hook Lug on the PHX was designed with a small footprint, which doesn’t disturb the shell vibration, and accentuates the fundamental tone. In addition, Yamaha’s unique 3.0mm aluminum die-cast hoop features high rigidity and extreme light weight, so it maximizes the head resonance, and creates a rich, melodic tone with a full attack.

Beautiful Shell Exteriors

The PHX range is not only packed with great features which make it a fantastic drum range, but it also has all the beauty of an exquisite, hand made musical instrument.

From the selection of the outer ply, chosen by the customer to be either traditional Maple or beautifully textured Ash, the decision making process begins. The shell is repeatedly painted and sanded, and then polished to a beautifully thin final finish of extreme hardness, which fully realizes the beauty and depth of the chosen outer veneer.

In addition, the textured finish is a specially prepared outer ply of figured Ash which is exclusively used on the PHX range. This special ply is less than half the thickness of a traditional coating, so it accentuates the beautiful wood grain of Ash but still allows the shell to fully vibrate.

Furthermore, the Hook Lugs and aluminum die-cast hoops are available in either chrome or a deeply exclusive gold, to match or contrast with the shells perfectly.

PHX

Las baterías prototipo, que son la base de lo que posteriormente serán las baterías de Yamaha, se crean en el laboratorio de percusión en donde YAMAHA busca la esencia de las baterías. Con un concepto completamente nuevo, la serie PHX (conocida también como Phoenix) representa la cumbre de la excelencia en este proceso de creación de prototipos. Fabricados a mano por técnicos expertos, los modelos de la serie PHX se basan en 40 años de historia y experiencia, y representan la búsqueda acérrima de Yamaha de lo más avanzado en baterías y una fuente de inspiración para los próximos 40 años.

Los colores y acabados pueden ser diferentes a estos en los productos actuales.
