| HiFi System |
| Center Unit |
Bluetooth Version/Profile |
Ver. 2.1 + EDR / A2DP, AVRCP ; [Audio Codec] SBC, AAC |
| Bluetooth Maximum Communication Range |
10 m / 32.8 ft. 10 in. (without interference) |
| Disc Type |
CD, CD-R, CD-RW (Audio CD, MP3, WMA) |
| USB |
Yes |
| Internet Radio |
Airable |
| Wi-Fi |
Yes |
| AirPlay |
Yes |
| DLNA |
Yes |
| File Format |
MP3, WMA, MPEG4, AAC, WAV(*1), FLAC(*1), AIFF(*1), ALAC(*2) --- (*1) 192 kHz / 24bit; (*2) 96 kHz / 24 bit |
| Ethernet |
Yes |
| Tuner |
DAB, DAB+, FM |
| Preset Memory |
DAB x 30, FM x 30 |
| Headphone Jack |
Yes |
| Digital Audio Input: Optical |
Yes |
| Total Harmonic Distortion(CD to Sp Out, 20 Hz-20 kHz) |
0.05 % (7.5W/6Ω 1KHz) |
| Dynamic Range |
100dB |
| Output Power/Channel (6 ohms, 1 kHz, 10% THD) |
70 W + 70 W |
| [Player] Harmonic Distortion + Noise (1 kHz) |
0.003% |
| [Player] Dimensions (W x H x D) |
314 x 70 x 338 mm; 12-3/8” x 2-3/4” x 13-1/4” |
| [Player] Weight |
2.9 kg; 6.5 lbs. |
| [Receiver] Dimensions (W x H x D) |
314 x 70 x 342 mm; 12-3/8” x 2-3/4” x 13-1/2” |
| [Receiver] Weight |
3.3 kg; 7.3 lbs. |
| Speaker System |
Tipo |
2-way bass-reflex bookshelf |
| Woofer |
13 cm (5-1/4”) cone |
| Tweeter |
3 cm (1-1/4”) soft dome |
| Input Power (Max/Nominal) |
120 W / 60 W |
| Frequency Response |
50 Hz–40 kHz |
| Sensitivity |
85 dB / 2.83 V / 1 m |
| Crossover Frequency |
3 kHz |
| Impedance |
6 ohms |
| Dimensions (W x H x D) |
176 x 310 x 327 mm; 6-7/8” x 12-1/4” x 12-7/8” |
| Weight |
5.9 kg; 13 lbs. |
